RTYS Industrial-Grade Disperser

It is a fast, high-capacity dispersing equipment with functions including mixing, dispersing and homogenizing, delivering excellent results and efficiency.

400-855-0306

info@root-asia.com

8613611698308

RTYS Industrial-Grade Disperser

description1

Zipper closure 1/4 zip athletic pullovers for men. Stretchy, lightweight, fast-drying fabric for superior performance. REGULAR FIT - US standard sizes. An athletic fit that sits close to the body for a wide range of motion, designed for optimal performance and all day comfort. FEATURES - Quarter zip closure;Thumbholes on long sleeves to keep them in place during workout

Product Introduction

The RTYS Floor-Standing Hydraulic Lifting Disperser is a fast, high-capacity dispersion equipment that integrates mixing, dispersing, and homogenizing functions, delivering excellent performance and efficiency.

Performance Features

1.Easy Operation, Safety and Durability

The operation is simple to reduce costs and save time; the hydraulic lifting is stable and firm. It is equipped with protection against accidental contact with the rotating shaft to ensure operational safety and extend the service life of the equipment.

2.Flexible Speed Regulation and Accessory Adaptability

Supports single-speed, dual-speed, and frequency conversion speed regulation. Equipped with a variety of easily replaceable dispersion discs to adapt to different materials; the clamping devices include three types: belt-driven, pneumatic, and hand-cranked, which can firmly fix the container.

3.Strong Customization and Functional Adaptability

Can be custom-designed non-standard according to customer needs; explosion-proof or ordinary types can be selected according to material conditions. It can measure temperature through rods or stirring shafts to improve the reliability of the production process.

4.Efficiently Meeting Multi-scenario Needs

With mixing, dispersing, and homogenizing functions, it features high processing efficiency and excellent results. It adapts to different processing volume requirements and is compatible with production and experimental scenarios in multiple industries.

Application Fields

biology

pharmaceuticals

health products

cosmetics

food

It can be widely applied in the production, product development, and experimentation fields of industries such as biology, pharmaceuticals, fine chemicals, cosmetics, health products, and food.

Technical Parameters

Model	Power(kW)	Rotational Speed(rpm)	Disc Diameter（mm)	Lifting Stroke(mm)	Pump Power (kW)	Throughput(L)
RTYS-4	4	0-1450	200	850	0.55	200
RTYS-7.5	7.5	0-1450	230	850	0.75	400
RTYS-11	11	0-1450	250	1000	0.75	500
RTYS-15	15	0-1450	280	1000	0.75	700
RTYS-18.5	18.5	0-1450	300	1200	0.75	800
RTYS-22	22	0-1450	350	1200	0.75	1000
RTYS-30	30	0-1450	400	1200	0.75	1500
RTYS-37	37	0-1450	400	1200	0.75	2000
RTYS-45	45	0-1450	450	1500	1.1	2500
RTYS-55	55	0-1450	500	1500	1.1	3000
RTYS-75	75	0-960	550	1800	2.2	4000
RTYS-90	90	0-960	600	1800	2.2	6000

RTYS Industrial-Grade Disperser
